QD B,C,D SHEAVES-600
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1005560 |
| Product Name | 6B56SK |
| Brand | Browning |
| Material | Cast Iron |
| Weight | 13.04 lb |
| Package Length | 6.06 in |
| Package Width | 6.06 in |
| Package Height | 4.75 in |
| Datum Diameter (A) | 5.2 |
| Outside Diameter (in) | 5.95 in |
| Number of Grooves | 6 |
| Pitch Diameter (A) | 5.4 |
| Pitch Diameter (B) |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $966.90 | — |
| 5 – 9 | $913.83 | 5% off |
| 10+ | $887.29 | 8% off |
| 5.9 |
| Bushing Used | SK |
| Pulley Material | Cast Iron |
| Datum Diameter (B) | 5.6 |
| Model Name | 6AB_LG_Sheavemaster |
| Belt Section | A, B |
| Bore (Min) (in) | 0.5 in |
| Product Type | Multiple Sheaves |
| Bore Type | QD Bushed |
| Bushing Bore Range | 0.500 - 2.625 |
| Pulley Construction | Plain |
| Overall Width (in) | 4.75 |
| Face Width (in) | 4.75 |
| HTC | 8483.50.9040 |
| Country of Origin | Mexico |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-101118 |
| Part NumberiManufacturer catalog number | 1005560 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289416448 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
