GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1055615 |
| Product Name | 26HB150 |
| Brand | Browning |
| Material | Steel |
| Weight | 8.6 lb |
| Package Length | 4.88 in |
| Package Width | 4.88 in |
| Package Height | 3.25 in |
| Width (mm) | 38.1 mm |
| Number of teeth | 26 |
| Product Type | Gearbelt Pulley |
| Bore Range | 3/4 to 2 1/4 |
| Model Name |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $406.36 | — |
| 5 – 9 | $376.93 | 7% off |
| 10+ | $360.85 | 11% off |
| GBPulley_Master2 |
| Bore Type | Rough Bore |
| Belt Section | H |
| Pitch Diameter (in) | 4.138 in |
| Outside Diameter (mm) | 103.7336 mm |
| Flange (in) | 4.370 in |
| Width (in) | 1.5 in |
| Outside Diameter (in) | 4.084 in |
| Face Width | 1.8125 |
| Pulley Construction | Solid |
| Hub Projection | 0.9375 |
| Length Through Bore | 2.75 |
| Overall Length (in) | 2.75 in |
| Bore Diameter (in) | 0.75 in |
| Hub Diameter (in) | 3.375 in |
| Number of Hubs | 1 |
| With Flanges | With Flanges |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102704 |
| Part NumberiManufacturer catalog number | 1055615 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289192656 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
