GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1055771 |
| Product Name | 17HB300 |
| Brand | Browning |
| Material | Steel |
| Weight | 5.2 lb |
| Package Length | 4.4 in |
| Package Width | 4.2 in |
| Package Height | 4.5 in |
| Product Type | Gearbelt Pulley |
| Bore Range | 3/4 to 1 1/4 |
| Number of teeth | 17 |
| Width (mm) | 76.2 mm |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $633.43 | — |
| 5 – 9 | $587.57 | 7% off |
| 10+ | $562.49 | 11% off |
| Rough Bore |
| Belt Section | H |
| Outside Diameter (in) | 2.652 in |
| Width (in) | 3 in |
| Pitch Diameter (in) | 2.706 in |
| Flange (in) | 3 in |
| Outside Diameter (mm) | 67.3608 mm |
| Face Width | 3.3125 |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102717 |
| Part NumberiManufacturer catalog number | 1055771 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289314355 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
