GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1055821 |
| Product Name | 22HB300 |
| Brand | Browning |
| Material | Steel |
| Weight | 8.535 lb |
| Package Length | 5.2 in |
| Package Width | 5.3 in |
| Package Height | 5.3 in |
| Width (mm) | 76.2 mm |
| Product Type | Gearbelt Pulley |
| Bore Range | 1 to 1 3/4 |
| Number of teeth | 22 |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $457.56 | — |
| 5 – 9 | $424.43 | 7% off |
| 10+ | $406.32 | 11% off |
| Rough Bore |
| Flange (in) | 3.735 in |
| Outside Diameter (in) | 3.447 in |
| Width (in) | 3 in |
| Outside Diameter (mm) | 87.5538 mm |
| Pitch Diameter (in) | 3.501 in |
| Belt Section | H |
| Face Width | 3.375 |
| Overall Length (in) | 4.3125 in |
| Pulley Construction | Solid |
| Number of Hubs | 1 |
| With Flanges | With Flanges |
| Length Through Bore | 4.3125 |
| Hub Diameter (in) | 2.75 in |
| Hub Projection | 0.9375 |
| Bore Diameter (in) | 1 in |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102721 |
| Part NumberiManufacturer catalog number | 1055821 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289132829 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
