GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1055854 |
| Product Name | 28HB300 |
| Brand | Browning |
| Material | Steel |
| Weight | 14.41 lb |
| Package Length | 5.4 in |
| Package Width | 5.3 in |
| Package Height | 5.1 in |
| Bore Range | 1 1/8 to 2 5/16 |
| Width (mm) | 76.2 mm |
| Product Type | Gearbelt Pulley |
| Number of teeth | 28 |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $642.90 | — |
| 5 – 9 | $596.35 | 7% off |
| 10+ | $570.90 | 11% off |
| Rough Bore |
| Outside Diameter (in) | 4.402 in |
| Belt Section | H |
| Flange (in) | 4.687 in |
| Width (in) | 3 in |
| Outside Diameter (mm) | 111.8108 mm |
| Pitch Diameter (in) | 4.456 in |
| Face Width | 3.375 |
| With Flanges | With Flanges |
| Bore Diameter (in) | 1.125 in |
| Number of Hubs | 1 |
| Overall Length (in) | 4.4375 in |
| Pulley Construction | Solid |
| Length Through Bore | 4.4375 |
| Hub Projection | 1.0625 |
| Hub Diameter (in) | 3.5 in |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102724 |
| Part NumberiManufacturer catalog number | 1055854 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289192885 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
