GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1057520 |
| Product Name | 72HQ300 |
| Brand | Browning |
| Material | Cast Iron |
| Weight | 22.1 lb |
| Package Length | 11.38 in |
| Package Width | 11.38 in |
| Package Height | 3.25 in |
| Bore Range | 3/4 to 2 11/16 |
| Number of teeth | 72 |
| Product Type | Gearbelt Pulley |
| Width (mm) | 76.2 mm |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $2260.36 | — |
| 5 – 9 | $2096.69 | 7% off |
| 10+ | $2007.22 | 11% off |
| Bushed Bore |
| Inside Diameter (in) | 10.5625 in |
| Pitch Diameter (in) | 11.459 in |
| Outside Diameter (in) | 11.405 in |
| Belt Section | H |
| Width (in) | 3 in |
| Outside Diameter (mm) | 289.687 mm |
| Face Width | 3.3125 |
| Hub Diameter (in) | 4.125 in |
| Hub Projection | 0.25 |
| Length Through Bore | 2.5 |
| Pulley Construction | Arm |
| With Flanges | No Flanges |
| Overall Length (in) | 3.5625 in |
| Number of Hubs | 1 |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102853 |
| Part NumberiManufacturer catalog number | 1057520 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289224265 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
