GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1057637 |
| Product Name | 30XHR200 |
| Brand | Browning |
| Material | Cast Iron |
| Weight | 23.53 lb |
| Package Length | 12.1 in |
| Package Width | 10.6 in |
| Package Height | 10 in |
| Width (mm) | 50.8 mm |
| Product Type | Gearbelt Pulley |
| Bore Range | 1 1/8 to 3 3/4 |
| Number of teeth | 30 |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $1054.10 | — |
| 5 – 9 | $977.77 | 7% off |
| 10+ | $936.05 | 11% off |
| Bushed Bore |
| Outside Diameter (in) | 8.246 in |
| Pitch Diameter (in) | 8.356 in |
| Width (in) | 2 in |
| Inside Diameter (in) | 6.5 in |
| Outside Diameter (mm) | 209.4484 mm |
| Flange (in) | 8.89 in |
| Belt Section | XH |
| Face Width | 2.5625 |
| Pulley Construction | Solid |
| Overall Length (in) | 3.156 in |
| Length Through Bore | 2.875 |
| With Flanges | With Flanges |
| Hub Projection | 0.59325 |
| Hub Diameter (in) | 5.36 in |
| Number of Hubs | 1 |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102861 |
| Part NumberiManufacturer catalog number | 1057637 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289314645 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
