GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1057678 |
| Product Name | 48XHR200 |
| Brand | Browning |
| Material | Cast Iron |
| Weight | 29.97 lb |
| Package Length | 14.2 in |
| Package Width | 14.2 in |
| Package Height | 3.4 in |
| Bore Range | 1 1/8 to 3 3/4 |
| Width (mm) | 50.8 mm |
| Product Type | Gearbelt Pulley |
| Number of teeth | 48 |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $3953.29 | — |
| 5 – 9 | $3667.03 | 7% off |
| 10+ | $3510.55 | 11% off |
| Bushed Bore |
| Outside Diameter (mm) | 336.7786 mm |
| Belt Section | XH |
| Outside Diameter (in) | 13.259 in |
| Width (in) | 2 in |
| Pitch Diameter (in) | 13.369 in |
| Inside Diameter (in) | 12 in |
| Face Width | 2.5625 |
| Number of Hubs | 1 |
| With Flanges | No Flanges |
| Hub Diameter (in) | 5.36 in |
| Hub Projection | 0.87525 |
| Length Through Bore | 2.875 |
| Overall Length (in) | 3.43725 in |
| Pulley Construction | ARM |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102865 |
| Part NumberiManufacturer catalog number | 1057678 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289314652 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
