Browning 4 Groove Cast Iron Bushed Bore Multiple Sheave - 4G3V26
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1059229 |
| Product Name | 4G3V26 |
| Brand | Browning |
| Material | Cast Iron |
| Weight | 1.54 lb |
| Package Length | 3.56 in |
| Package Width | 3.56 in |
| Package Height | 2.25 in |
| Pulley Material | Cast Iron |
| Pitch Diameter (3V) | 2.6 |
| Overall Length (in) | 2.40625 in |
| Outside Diameter (in) | 2.65 in |
| Bushing Used |
Datasheets, CAD drawings, and installation instructions are available on request.
Request Documentation| G |
| Number of Grooves | 4 |
| Bore (Min) (in) | 0.375 in |
| Belt Section | 3V |
| Product Type | Multiple Sheaves |
| Bore Type | Split Taper Bushed |
| Bushing Bore Range | 0.375 - 1.000 |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-102924 |
| Part NumberiManufacturer catalog number | 1059229 |
| BrandiManufacturer or product brand | Browning |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
