Browning 1 Groove Cast Iron Bushed Bore Multiple Sheave - 13V1900SK
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1064443 |
| Product Name | 13V1900SK |
| Brand | Browning |
| Material | Cast Iron |
| Weight | 25.58 lb |
| Package Length | 19.75 in |
| Package Width | 19.75 in |
| Package Height | 1.75 in |
| Pulley Material | Cast Iron |
| Number of Grooves | 1 |
| Outside Diameter (in) | 19 in |
| Pitch Diameter (3V) | 18.95 |
| Bushing Used |
Datasheets, CAD drawings, and installation instructions are available on request.
Request Documentation| SK |
| Bore (Min) (in) | 0.5 in |
| Belt Section | 3V |
| Product Type | Multiple Sheaves |
| Bore Type | QD Bushed |
| Bushing Bore Range | 0.500 - 2.625 |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-103258 |
| Part NumberiManufacturer catalog number | 1064443 |
| BrandiManufacturer or product brand | Browning |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
