SPLITTAPERBUSH-600
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1070838 |
| Product Name | R1 30 MM |
| Brand | Browning |
| Material | Sintered Steel or Ductile Iron |
| Weight | 9.7 lb |
| Package Length | 5.38 in |
| Package Width | 3 in |
| Package Height | 5.38 in |
| Bore Size (mm) | 30 mm |
| Outside Diameter (in) | 5.375 in |
| Keyseat (mm) | 8 x 3.5 mm |
| Cap Screws (Size) | 3/8 x 1 3/4 |
| Bushing Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $436.23 | — |
| 5 – 9 | $403.06 | 8% off |
| 10+ | $383.84 | 12% off |
| R1 |
| Total Length (mm) | 73.025 mm |
| Product Type | Split Taper Bushing |
| Total Length (in) | 2.875 in |
| Length Through Bore (mm) | 73.025 mm |
| Wrench Torque (in-lb) | 348 |
| Compatible Bore Size [Max] (mm) | 30 mm |
| Model Name | R1-R2_Type1_BushingMaster |
| Outside Diameter (mm) | 136.525 mm |
| Cap Screws (No.) | 3 |
| Bore Type | Metric |
| HTC | 8483.90.8080 |
| Country of Origin | Mexico |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-103611 |
| Part NumberiManufacturer catalog number | 1070838 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289411726 |
| CategoryiCatalog classification | Split Taper Bushings |
