QD BUSHINGS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1074996 |
| Product Name | M 3 3/8 |
| Brand | Browning |
| Material | Gray Iron - G3025 |
| Weight | 52.8 lb |
| Package Length | 10.13 in |
| Package Width | 10.13 in |
| Package Height | 5.13 in |
| Torque Capacity (in-lb) | 85,000 |
| Mounting Type | Conventional |
| Total Length (in) | 6.76 in |
| Product Type | Q-D Bushing |
| Model Name |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $1856.76 | — |
| 5 – 9 | $1741.29 | 6% off |
| 10+ | $1696.94 | 9% off |
| QD-M_Bushing_Master |
| Cap Screws (Bolt Circle) | 7.875 |
| Cap Screws (Size) | 3/4-10 x 6 3/4 |
| Length Through Bore (in) | 6.76 in |
| Wrench Torque (ft.-lbs.) | 225 |
| Bore Type | Inch |
| Bushing Type | M |
| Compatible Bore Size [Max] (in) | 3.375 in |
| Cap Screws (No.) | 4 |
| Keyway | 7/8 x 7/16 |
| Outside Diameter (in) | 9 in |
| Bore Size (in) | 3.375 in |
| Barrel Length | 5.51 in |
| Flange Thickness | 1.25 in |
| Barrel Diameter | 6.5 in |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-103854 |
| Part NumberiManufacturer catalog number | 1074996 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289401024 |
| CategoryiCatalog classification | Q-D Bushings |
