SPLIT TAPER BUSHINGS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1081165 |
| Product Name | W1 7 7/16 |
| Brand | Browning |
| Material | Ductile Iron or Gray Iron |
| Weight | 104 lb |
| Package Length | 18.5 in |
| Package Width | 12 in |
| Package Height | 11.5 in |
| Product Type | Split Taper Bushing |
| Bore Size (in) | 7.4375 in |
| Total Length (in) | 8.25 in |
| Wrench Torque (in-lb) | 3,000 |
| Model Name |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $8137.14 | — |
| 5 – 9 | $7518.37 | 8% off |
| 10+ | $7159.81 | 12% off |
| W1-T2_BushingMaster |
| Cap Screws (Size) | 3/4 x 3 |
| Bushing Type | W1 |
| Outside Diameter (in) | 12.5 in |
| Length Through Bore (in) | 8.25 in |
| Keyseat | 1 3/4 x 3/4 |
| Compatible Bore Size [Max] (in) | 7.4375 in |
| Bore Type | Inch |
| Cap Screws (No.) | 4 |
| HTC | 8483.90.8080 |
| Country of Origin | Mexico |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-104292 |
| Part NumberiManufacturer catalog number | 1081165 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289148356 |
| CategoryiCatalog classification | Split Taper Bushings |
