GEARBELTS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1097260 |
| Product Name | 600H100 |
| Brand | Browning |
| Material | Neoprene |
| Weight | 0.79 lb |
| Package Length | 14 in |
| Package Width | 6.5 in |
| Package Height | 2 in |
| Product Type | Gearbelt |
| Belt Section | H |
| Outside Length/Diameter (in) | 60 in |
| Operating Temperature [Max] ºF | 180 °F |
| Operating Temperature [Max] ºC |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $261.60 | — |
| 82.2 °C |
| Std Package Quantity | 1 |
| Pitch Designation (mm) | 203.2 |
| Number of teeth | 120 |
| Tooth Profile | Curved |
| Reinforcing cord material | Fiberglass |
| HTC | 4010.36.4500 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-104908 |
| Part NumberiManufacturer catalog number | 1097260 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289239870 |
| CategoryiCatalog classification | Belts |
