TYPE A SPROCKETS-900
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1108810 |
| Product Name | 50A21 |
| Brand | Browning |
| Material | Steel |
| Weight | 1.1 lb |
| Package Length | 9.25 in |
| Package Width | 9.25 in |
| Package Height | 3.75 in |
| Chain Pitch (in) | 0.625 in |
| Product Type | Type "A" Plate Sprocket |
| Chain Used | No. 50, 5/8 in. Pitch ANSI Chain |
| Number of Teeth | 21 |
| Tooth Width (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $141.48 | — |
| 5 – 9 | $128.89 | 9% off |
| 10+ | $99.71 | 30% off |
| 0.343 in |
| Outside Diameter (in) | 4.522 in |
| Bore Type | Minimum Plain Bore |
| Overall Length (in) | 0.343 in |
| Length Through Bore (in) | 0.343 in |
| Hub Type | Type A |
| Sprocket Material | Steel, Hardened Teeth |
| Chain Number | No. 50, 5/8 in. Pitch ANSI Chain |
| Pitch Diameter (in) | 4.193441 in |
| Number of Strands/Width | 1 |
| Bore Diameter (in) | 0.75 in |
| Maximum Bore (in) | 2.25 in |
| Minimum Bore (mm) | 20 mm |
| Maximum Bore (mm) | 57 mm |
| Number of Hubs | 0 |
| Hardened Teeth | With Hardened Teeth |
| HTC | 8483.90.1050 |
| Country of Origin | China |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-105065 |
| Part NumberiManufacturer catalog number | 1108810 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289201419 |
| CategoryiCatalog classification | Sprockets |
