FINISHED BORE SPROCKETS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1128446 |
| Product Name | H4024X5/8 |
| Brand | Browning |
| Material | Steel, Hardened Teeth |
| Weight | 2.28 lb |
| Package Length | 4.19 in |
| Package Width | 4.19 in |
| Package Height | 1.06 in |
| Chain Pitch (in) | 0.5 in |
| Product Type | Finished Bore Roller Chain Sprocket |
| Pitch Diameter (in) | 3.831 in |
| Number of Teeth | 24 |
| Chain Used |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $227.95 | — |
| 5 – 9 | $207.66 | 9% off |
| 10+ | $160.65 | 30% off |
| No. 40, 1/2 in. Pitch ANSI Chain |
| Outside Diameter (in) | 4.098 in |
| Bore Type | Finished Bore |
| Bore Diameter (in) | 0.625 in |
| Number of Strands/Width | 1 |
| Hub Diameter (in) | 3.266 in |
| Hub Projection (in) | 0.71875 in |
| Tooth Width (in) | 0.284 in |
| Length Through Bore (in) | 1 in |
| Hub Type | Type B |
| Pitch Type | Single |
| Hardened Teeth | With Hardened Teeth |
| Keyway Size | 3/16 x 3/32 |
| Maximum Bore (mm) | 0 mm |
| Maximum Bore (in) | 0.63 in |
| Minimum Bore (mm) | 0 mm |
| HTC | 8483.90.1050 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-105155 |
| Part NumberiManufacturer catalog number | 1128446 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289283385 |
| CategoryiCatalog classification | Sprockets |
