FINISHED BORE SPROCKETS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1129246 |
| Product Name | H6014X 1 7/16 |
| Brand | Browning |
| Material | Steel, Hardened Teeth |
| Weight | 1.58 lb |
| Package Length | 4.56 in |
| Package Width | 4.56 in |
| Package Height | 1.56 in |
| Pitch Diameter (in) | 3.371 in |
| Number of Teeth | 14 |
| Chain Pitch (in) | 0.75 in |
| Chain Used | No. 60, 3/4 in. Pitch ANSI Chain |
| Product Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $189.26 | — |
| 5 – 9 | $172.41 | 9% off |
| 10+ | $133.39 | 30% off |
| Finished Bore Roller Chain Sprocket |
| Outside Diameter (in) | 3.736 in |
| Bore Type | Finished Bore |
| Number of Strands/Width | 1 |
| Bore Diameter (in) | 1.4375 in |
| Hub Diameter (in) | 2.578 in |
| Hub Type | Type B |
| Length Through Bore (in) | 1.25 in |
| Hub Projection (in) | 0.796875 in |
| Tooth Width (in) | 0.459 in |
| Hardened Teeth | With Hardened Teeth |
| Pitch Type | Single |
| Keyway Size | 3/8 X 3/16 |
| Minimum Bore (mm) | 0 mm |
| Maximum Bore (in) | 1.44 in |
| Maximum Bore (mm) | 0 mm |
| HTC | 8483.90.1050 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-105160 |
| Part NumberiManufacturer catalog number | 1129246 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289134243 |
| CategoryiCatalog classification | Sprockets |
