BEVEL/MITER GEARS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1229442 |
| Product Name | YSM12F15X1/2 |
| Brand | Browning |
| Material | Steel |
| Weight | 0.18 lb |
| Package Length | 2.56 in |
| Package Width | 2.56 in |
| Package Height | 1.38 in |
| Pitch Diameter (in) | 1.25 in |
| Mounting Distance | 1.25 |
| Face Width (in) | 0.27 in |
| Number of Teeth/Threads | 15 |
| Pressure Angle |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $96.51 | — |
| 5 – 29 | $93.91 | 3% off |
| 30 – 49 | $83.53 | 13% off |
| 50+ | $75.97 | 21% off |
Datasheets, CAD drawings, and installation instructions are available on request.
Request Documentation| 20 |
| Hub Diameter (in) | 1 in |
| Diametral Pitch | 12 |
| Hub Projection (in) | 0.5 in |
| Bore (Min) (in) | 0.5 in |
| Bore (Max) (in) | 0.5 in |
| Bore Type | Finished Bore |
| Length Through Bore (in) | 0.859375 in |
| Product Type | Miter Gear |
| Bore Size (in) | 0.5 in |
| HTC | 8483.40.9000 |
| Country of Origin | India |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-105983 |
| Part NumberiManufacturer catalog number | 1229442 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289257003 |
| CategoryiCatalog classification | Gearing |
