B200 SERIES CLUTCH
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 172704 |
| Product Name | B207A CL |
| Brand | Morse |
| Weight | 1.25 lb |
| Package Length | 3.7 in |
| Package Width | 3.3 in |
| Package Height | 2.4 in |
| Type | Mechanical Clutches |
| Bearing Size to Use with Clutch | 207 |
| Model | B207A |
| Overall Width (in) | 1.125 in |
| Std Package Quantity | 1 |
| Overall Diameter (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 9 | $480.04 | — |
| 10+ | $445.46 | 7% off |
| 2.8326 in |
| Key Size | 1/4 x 1/8 in |
| RPM Max. - Inner Race (shaft) | 2,000 |
| Add'l Bearing Support Requirement | Yes |
| Product Type | B200 Series |
| Backstopping Clutch | Yes |
| Rated Torque Capacity (ft.-lbs.) | 275 |
| Overrunning Clutch | Yes |
| Bore Size (in) | 1.657 in |
| Indexing Clutch | Yes |
| RPM Max. -inner Race | 2,000 |
| Outer Width (in) | 1.125 in |
| Lubrication Type | Grease |
| HTC | 8483.60.4040 |
| Country of Origin | Mexico |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-107563 |
| Part NumberiManufacturer catalog number | 172704 |
| BrandiManufacturer or product brand | Morse |
| UPCiUniversal Product Code | 662961739094 |
| CategoryiCatalog classification | Power Transmission > Belt Drive Accessories |
