TORQ/PRO
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 187800 |
| Product Name | TP50LX 1 3/8 |
| Brand | Browning |
| Weight | 13 lb |
| Package Length | 6.25 in |
| Package Width | 6.25 in |
| Package Height | 3.5 in |
| Sensor Plate | Yes |
| Bore Size (in) | 1.375 in |
| Detection Method | Ball Detent |
| Mounting Bolt Circle Diameter | 5.5 |
| Nut Diameter (in) | 3.86 in |
| Nominal Bore (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 9 | $4226.43 | — |
| 10+ | $4026.14 | 5% off |
| 1.375 in |
| Recovery Style | Jog |
| Type | Torque Overload Devices |
| Outside Diameter (in) | 6.25 in |
| Sensor Travel | 0.11 |
| Unit Accuracy | 0.1 |
| Series / Model | TP50L |
| Total Length (in) | 3.19 in |
| Total Length (mm) | 81.026 mm |
| Bolt Hole Thread Size (in) | 5/16 | 18 in |
| Backlash | Small |
| Disconnect Method | Ball Detent |
| Speed Limit | 300 |
| Number of Bolt Holes | 6 |
| Bore Size (mm) | 34.925 mm |
| Reset Type | Automatic |
| Spring Diameter | 4.59 |
| Torque [Min] (N-m) | 67.8 |
| Disc Spring Color | Yellow |
| Bore Shape | Straight Bore |
| Torq/Pro Sprockets | STP50 |
| Outside Diameter (mm) | 158.75 mm |
| Hub Diameter (in) | 2.76 in |
| Torque Capacity [Max] (lb-ft) | 108.333333333333 |
| Torque Capacity [Min] (lb-ft) | 50 |
| Bore (Max) (in) | 1.375 in |
| Product Type | Torq Pro Torque Limiter |
| Flange Diameter (in) | 4.8 in |
| Torque [Max] (N-m) | 146.9 |
| Max RPM | 300 |
| Torque Capacity [Min] (in-lb) | 600 |
| Torque [Max] (in-Ibs) (1 Spring) | 1,300 |
| Torque Capacity [Max] (in-lb) | 1,300 |
| Bore (Min) (in) | 1.375 in |
| Bore Type | Finished w/ Keyway |
| Pilot Size | 6.25 |
| HTC | 8483.60.8000 |
| Country of Origin | Japan |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-107684 |
| Part NumberiManufacturer catalog number | 187800 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662288442592 |
| CategoryiCatalog classification | Power Transmission > Belt Drive Accessories |
