FAST COUPLING-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1960582 |
| Product Name | 3 SB RHUB |
| Brand | Kop-Flex |
| Material | Carbon Steel |
| Weight | 40.845 lb |
| Package Length | 9.6 in |
| Package Width | 9.6 in |
| Package Height | 4.4 in |
| Bolt Type | Shrouded |
| Bore Size Max (in) | 4.75 in |
| Bore Type | Rough Bore |
| Component Type | Rigid Hub |
| Configuration |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $974.85 | — |
| Gear |
| Coupling Size | 3 |
| Coupling Type | Gear Coupling |
| Hub Diameter (in) | 6.75 in |
| Length Through Bore (in) | 3.4688 in |
| Length Through Bore (mm) | 88.10625 mm |
| Lube/Non-Lube | Lubricated |
| Max Bore w/standard key for Rigid Hub | 4.75 in |
| Measurement System | Imperial |
| Model | Series H |
| Outside Diameter (in) | 9.4375 in |
| Size Code | 3 |
| Sleeve Outside Diameter (in) | 9.4375 in |
| Speed Max (rpm) | 6,800 rpm |
| Tooth Profile | Crowned |
| Torque Rating (in-lb) | 101,000 in/lbs |
| HTC | 8483.90.8010 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-107926 |
| Part NumberiManufacturer catalog number | 1960582 |
| BrandiManufacturer or product brand | Kop-Flex |
| UPCiUniversal Product Code | 662384110210 |
| CategoryiCatalog classification | Couplings |
