MORSE BRIT. STD. ACCESS-900
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 2361459 |
| Product Name | 08B-3 C/L SC |
| Brand | Morse |
| Material | Steel |
| Weight | 0.475 lb |
| Package Length | 1.25 in |
| Package Width | 1.75 in |
| Package Height | 0.45 in |
| Roller Diameter (mm) | 8.51 mm |
| Number of Strands/Width | 3 |
| Chain Size | 08 |
| Roller Width (mm) | 7.75 mm |
| Pin Diameter (mm) |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $53.45 | — |
Datasheets, CAD drawings, and installation instructions are available on request.
Request Documentation| 4.45 mm |
| Connecting Link - Slip Fit | Spring Clip |
| Product Type | Roller Chain |
| Chain Pitch (in) | 0.5 in |
| Chain Type | British Standard |
| Link Type | Offset Link |
| Overall Width/Pin Length (in) | 1.86 in |
| Inside Plate Height (in) | 0.464566929133858 in |
| HTC | 7315.19.0000 |
| Country of Origin | China |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-110123 |
| Part NumberiManufacturer catalog number | 2361459 |
| BrandiManufacturer or product brand | Morse |
| UPCiUniversal Product Code | 662460388205 |
| CategoryiCatalog classification | Power Transmission > Chain Accessories |
