KK CLUTCH-900
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 2657104 |
| Product Name | KK20 |
| Brand | Morse |
| Weight | 0.26 lb |
| RPM Max. -inner Race | 3,000 |
| Mounting Housing Diameter | 1.8499/1.8493 |
| Overall Diameter (in) | 1.85 in |
| Overall Diameter (mm) | 47 mm |
| Static Radial Load Rating (lb) | 1101.6 |
| Corner Radius | 1 |
| RPM Max. - Outer Race | 1600 |
| Mounting Shaft Diameter | 0.7885/0.788 |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 9 | $412.48 | — |
| 10+ | $382.75 | 7% off |
| Type | CAM Clutches |
| Lubrication Type | Grease |
| Overall Width (in) | 0.551 in |
| Dynamic Radial Load Rating (lb) | 1910.9 |
| Add'l Bearing Support Requirement | No |
| Product Type | KK Series |
| Rated Torque Capacity (ft.-lbs.) | 45 |
| Overrunning Clutch | Yes |
| Bore Size (mm) | 20 mm |
| Backstopping Clutch | Yes |
| Indexing Clutch | Yes |
| HTC | 8483.60.4040 |
| Country of Origin | Japan |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-111017 |
| Part NumberiManufacturer catalog number | 2657104 |
| BrandiManufacturer or product brand | Morse |
| UPCiUniversal Product Code | 662288927396 |
| CategoryiCatalog classification | Power Transmission > Belt Drive Accessories |
