R2 PKG CHAIN 80 & ABOVE
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 343661 |
| Product Name | 200-3R 10FT |
| Brand | Morse |
| Material | Steel |
| Weight | 32.04 lb |
| Roller Diameter (in) | 1.562 in |
| Chain Construction | Riveted |
| Chain Family | 200 |
| Number of Connecting Links Included | 1 |
| Pin Diameter (in) | 0.781 in |
| Roller Width (in) | 1.5 in |
| Number of Strands/Width | 3 |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $2533.39 | — |
Datasheets, CAD drawings, and installation instructions are available on request.
Request Documentation| Chain Pitch (in) |
| 2.5 in |
| Product Type | Roller Chain |
| Chain Type | Standard |
| Coating | Uncoated |
| Standard Met | ANSI B29.1 |
| Measurement System | Imperial |
| Transverse Pitch (in) | 2.817 in |
| Minimum Tensile Strength (lbs) | 234,375 lb |
| Inside Plate Height (in) | 2.25 in |
| Pin Length (in) | 8.754 in |
| Width Over Pins/Total Width (in) | 8.754 in |
| Total Length (ft) | 10 ft |
| Side Plate Configuration | Hourglass |
| Plate Thickness (in) | 0.312 in |
| Base Catalog No | 200-3 |
| HTC | 7315.11.0060 |
| Country of Origin | Taiwan, Republic of China |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-112542 |
| Part NumberiManufacturer catalog number | 343661 |
| BrandiManufacturer or product brand | Morse |
| UPCiUniversal Product Code | 662288860174 |
| CategoryiCatalog classification | Roller Chain |
