QD GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 3513843 |
| Product Name | 84H100SF |
| Brand | Browning |
| Material | Cast Iron |
| Weight | 17.45 lb |
| Package Length | 14.3 in |
| Package Width | 14.3 in |
| Package Height | 2.5 in |
| Bore Range | 1/2 to 2 15/16 |
| Width (mm) | 25.4 mm |
| Model Name | GBPulley_Master6 |
| Product Type | Gearbelt Pulley |
| Number of teeth |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $1722.54 | — |
| 5 – 9 | $1615.64 | 6% off |
| 10+ | $1559.23 | 9% off |
| 84 |
| Bore Type | Bushed Bore |
| Outside Diameter (mm) | 338.201 mm |
| Outside Diameter (in) | 13.315 in |
| Inside Diameter (in) | 12.25 in |
| Width (in) | 1 in |
| Belt Section | H |
| Pitch Diameter (in) | 13.369 in |
| Face Width | 1.3125 |
| Overall Length (in) | 2.3722 in |
| With Flanges | No Flanges |
| Hub Projection | 1.062 |
| Number of Hubs | 1 |
| Pulley Construction | Arm |
| Length Through Bore | 2 |
| Hub Diameter (in) | 4.625 in |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-112611 |
| Part NumberiManufacturer catalog number | 3513843 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289354054 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
