QD GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 3513967 |
| Product Name | 30H150SD |
| Brand | Browning |
| Material | Steel |
| Weight | 5.74 lb |
| Package Length | 5.06 in |
| Package Width | 5.06 in |
| Package Height | 1.88 in |
| Product Type | Gearbelt Pulley |
| Width (mm) | 38.1 mm |
| Model Name | GBPulley_Master6 |
| Bore Range | 1/2 to 2 |
| Number of teeth |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $613.17 | — |
| 5 – 9 | $575.12 | 6% off |
| 10+ | $555.04 | 9% off |
| 30 |
| Bore Type | Bushed Bore |
| Outside Diameter (in) | 4.721 in |
| Width (in) | 1.5 in |
| Belt Section | H |
| Flange (in) | 5.0000 in |
| Pitch Diameter (in) | 4.775 in |
| Outside Diameter (mm) | 119.9134 mm |
| Inside Diameter (in) | 3.75 in |
| Face Width | 1.8125 |
| Length Through Bore | 1.83 |
| Pulley Construction | Solid |
| With Flanges | With Flanges |
| Overall Length (in) | 2.26225 in |
| Number of Hubs | 1 |
| Hub Diameter (in) | 3.13 in |
| Hub Projection | 0.45 |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-112616 |
| Part NumberiManufacturer catalog number | 3513967 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289349616 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
