QD GEARBELT PULLEYS-500
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 3514551 |
| Product Name | 30XH200E |
| Brand | Browning |
| Material | Steel |
| Weight | 22.97 lb |
| Package Length | 10.1 in |
| Package Width | 10.4 in |
| Package Height | 3 in |
| Number of teeth | 30 |
| Bore Range | 7/8 to 3 1/2 |
| Width (mm) | 50.8 mm |
| Product Type | Gearbelt Pulley |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $2355.31 | — |
| 5 – 9 | $2209.15 | 6% off |
| 10+ | $2132.01 | 9% off |
| Bushed Bore |
| Flange (in) | 8.906 in |
| Belt Section | XH |
| Width (in) | 2 in |
| Pitch Diameter (in) | 8.356 in |
| Outside Diameter (mm) | 209.4484 mm |
| Outside Diameter (in) | 8.246 in |
| Inside Diameter (in) | 6.5 in |
| Face Width | 2.562 |
| Length Through Bore | 2.64 |
| Pulley Construction | Solid |
| With Flanges | With Flanges |
| Number of Hubs | 1 |
| Hub Diameter (in) | 6 in |
| Overall Length (in) | 3.416 in |
| Hub Projection | 0.853 |
| HTC | 8483.50.9080 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-112646 |
| Part NumberiManufacturer catalog number | 3514551 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289349760 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
