QD GEARBELT PULLEYS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 3514619 |
| Product Name | 72XH200F |
| Brand | Browning |
| Material | Steel |
| Weight | 57 lb |
| Package Length | 19.95 in |
| Package Width | 19.95 in |
| Package Height | 2.59 in |
| Number of teeth | 72 |
| Product Type | Gearbelt Pulley |
| Width (mm) | 50.8 mm |
| Bore Range | 1 to 4 |
| Bore Type |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $2895.25 | — |
| 5 – 9 | $2715.58 | 6% off |
| 10+ | $2620.75 | 9% off |
| Bushed Bore |
| Outside Diameter (mm) | 506.5776 mm |
| Outside Diameter (in) | 19.944 in |
| Width (in) | 2 in |
| Inside Diameter (in) | 18.6875 in |
| Pitch Diameter (in) | 20.054 in |
| Belt Section | XH |
| Face Width | 2.5625 |
| Pulley Construction | Arm |
| With Flanges | No Flanges |
| Hub Diameter (in) | 4.4375 in |
| Length Through Bore | 3.61 |
| Hub Projection | 1.59375 |
| Number of Hubs | 1 |
| Overall Length (in) | 4.15625 in |
| HTC | 8483.50.9080 |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-112649 |
| Part NumberiManufacturer catalog number | 3514619 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289353866 |
| CategoryiCatalog classification | Power Transmission > V-Belt Sheaves |
