B BUSHINGS-600
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 3694759 |
| Product Name | B 15/16 |
| Brand | Browning |
| Material | Sintered Steel or Ductile Iron |
| Weight | 3.055 lb |
| Package Length | 4.3 in |
| Package Width | 4.4 in |
| Package Height | 2.5 in |
| Wrench Torque (in-lb) | 192 |
| Cap Screws (Size) | 5/16 x 1 1/4 |
| Bushing Type | B |
| Total Length (in) | 1.9375 in |
| Length Through Bore (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $92.86 | — |
| 5 – 9 | $86.16 | 7% off |
| 10+ | $81.85 | 12% off |
| 1.9375 in |
| Bore Size (in) | 0.9375 in |
| Keyseat | 1/4 x 1/8 |
| Outside Diameter (in) | 3.6875 in |
| Model Name | B_Bushing-Type1_Master |
| Compatible Bore Size [Max] (in) | 0.9375 in |
| Product Type | Split Taper Bushing |
| Cap Screws (No.) | 3 |
| Bore Type | Inch |
| Mounting Type | Conventional |
| Flange Type | Solid Flange |
| Flange Thickness | 0.5 |
| Screw Length | 1.25 |
| Barrel Diameter (Large End) | 2.625 |
| Barrel Diameter (Small End) | 2.5567 |
| Bolt Circle Diameter (in) | 3.125 |
| Includes | Cap Screws and Ext. Key |
| Thread Size | 5/16-18 |
| HTC | 8483.90.8080 |
| Country of Origin | Mexico |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-112929 |
| Part NumberiManufacturer catalog number | 3694759 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289038473 |
| CategoryiCatalog classification | Split Taper Bushings |
