B BUSHINGS-600
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 3695434 |
| Product Name | B 40 MM |
| Brand | Browning |
| Material | Sintered Steel or Ductile Iron |
| Weight | 2.45 lb |
| Package Length | 4.3 in |
| Package Width | 4.4 in |
| Package Height | 2.5 in |
| Product Type | Split Taper Bushing |
| Outside Diameter (mm) | 93.6625 mm |
| Outside Diameter (in) | 3.6875 in |
| Bushing Type | B |
| Keyseat (mm) |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 4 | $49.76 | — |
| 5 – 9 | $46.17 | 7% off |
| 10+ | $43.86 | 12% off |
| 12 x 4 mm |
| Compatible Bore Size [Max] (mm) | 40 mm |
| Bore Size (mm) | 40 mm |
| Cap Screws (Size) | 5/16 x 1 1/4 |
| Length Through Bore (mm) | 49.2125 mm |
| Wrench Torque (in-lb) | 192 |
| Total Length (in) | 1.9375 in |
| Total Length (mm) | 49.2125 mm |
| Model Name | B_Bushing-Type1_Master |
| Bore Type | Metric |
| Cap Screws (No.) | 3 |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-112971 |
| Part NumberiManufacturer catalog number | 3695434 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289402779 |
| CategoryiCatalog classification | Split Taper Bushings |
