GEN GOLD SKWEZLOC
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 705854 |
| Product Name | SFC-38TC |
| Brand | Sealmaster |
| Weight | 11.7 lb |
| Package Length | 7.5 in |
| Package Width | 7.38 in |
| Package Height | 2.63 in |
| Overall Width (in) | 7.13 in |
| Bolt Size (in) | 1/2 in |
| Overall Length (in) | 7.13 in |
| Overall Height (in) | 2.63 in |
| Bore Diameter (in) | 2.375 in |
| Pilot Diameter (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $2466.75 | — |
| 5.000 in |
| Foot Height (in) | 0.50 in |
| Length Through Bore (in) | 2.625 in |
| Housing Outside Diameter (in) | 7.125 in |
| Bolt Circle (in) | 6 in |
| Bore Shape | Straight |
| Rolling Element | Ball Bearing |
| Pilot Configuration | Piloted |
| Housing Construction | One Piece |
| Housing Color | Black |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Cage Material | PPS - Polyphenylene Sulfide |
| Housing Type | Piloted Flange Cartridge |
| Seal Type | Single Lip Contact Seal |
| Housing Style | Flange Block |
| Inner Race Heat Treat Method | Zone-Hardened |
| Ability to Relubricate | Yes |
| Locking Collar Outside Diameter (in) | 4.06 in |
| Pilot Depth (in) | 0.844 in |
| Housing Coating | Powder Coated |
| Maximum Speed (RPM) | 2550 rpm |
| Shaft Locking Type | Concentric |
| Size Code | 2-27 |
| Lubricant | Lithium Complex NLGI 2 Grease |
| Radial Clearance | Standard |
| Static Load Rating (lb) | 8,150 lb |
| Grease Fitting Thread Size | 1/8 NPT |
| Insert | 2-26TC SFB ATO |
| Fixed vs. Expansion | Fixed |
| Bearing Type | Standard Duty |
| Misalignment Capability | ±2.0° Misalignment - Static Only |
| Bearing Insert Finish | Black Oxide |
| Max Operating Temperature (F) | 220 °F |
| Dynamic Load Rating (lb) | 11,789 lb |
| Inner Ring Outside Diameter (in) | 2.984 in |
| Housing Material | Cast Iron |
| End Cap Available | No |
| Cage Type | Land Riding Retainer |
| Bearing Insert Material | 52100 Bearing Steel |
| HTC | 8483.20.4040 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-117135 |
| Part NumberiManufacturer catalog number | 705854 |
| BrandiManufacturer or product brand | Sealmaster |
| UPCiUniversal Product Code | 662461033340 |
| CategoryiCatalog classification | Bearings > Ball Bearings |
