PN GOLD
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 711383 |
| Product Name | CRPS-PN32R |
| Brand | Sealmaster |
| Weight | 8.26 lb |
| Package Length | 9 in |
| Package Width | 5.19 in |
| Package Height | 2.38 in |
| Overall Length (in) | 8.63 in |
| Base Width (in) | 2.38 in |
| Overall Width (in) | 2.38 in |
| Overall Height (in) | 4.56 in |
| Bolt Size (in) | 5/8 in |
| Bore Diameter (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $815.72 | — |
| 2 in |
| Base to Center Height (in) | 2.2500 in |
| Foot Height (in) | 0.75 in |
| Length Through Bore (in) | 2.031 in |
| Bolt Spacing Min (in) | 6 in |
| Centerline to Outermost Bearing Face (in) | 1.281 in |
| Bolt Spacing Max (in) | 6.5 in |
| Rolling Element | Ball Bearing |
| Housing Base | Solid |
| Bore Shape | Straight |
| Housing Construction | One Piece |
| Outer Ring Land Profile | Standard |
| Housing Color | Silver |
| Options | Corrosion Resistant |
| Misalignment Type | Static Only |
| Certifications | IP69K |
| Cage Material | PPS - Polyphenylene Sulfide |
| Housing Type | Pillow Block, Two Bolt |
| Seal Type | Multi-Lip Contact Seal |
| Housing Style | Pillow Block |
| Ability to Relubricate | Yes |
| Inner Race Heat Treat Method | Zone-Hardened |
| End Cap Available | Yes |
| Fixed vs. Expansion | Fixed |
| Radial Clearance | Standard |
| Grease Fitting Thread Size | 1/8 NPT |
| Vibration Frequency Outer Ring Defect | 0.0683 cps |
| Static Load Rating (lb) | 5,216 lb |
| Bearing Type | Standard Duty |
| Cage Type | Land Riding Retainer |
| Shaft Locking Type | Set Screw |
| Max Operating Temperature (F) | 220 °F |
| Size Code | 2-115 |
| Lubricant | Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease |
| Bearing Insert Material | 52100 Bearing Steel |
| Bearing Insert Finish | Phosphorus Nickel Coated |
| Insert | PN-32R |
| Vibration Frequency Fundamental Train | 0.0068 cps |
| Vibration Frequency Inner Ring Defect | 0.0984 cps |
| Maximum Speed (RPM) | 1500 rpm |
| Vibration Frequency Roller Spin | 0.0445 cps |
| Inner Ring Outside Diameter (in) | 2.469 in |
| Base Length (in) | 8.13 in |
| Housing Material | Stainless Steel |
| Misalignment Capability | ±2.0° Misalignment - Static Only |
| Dynamic Load Rating (lb) | 7,889 lb |
| HTC | 8483.20.8040 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-117866 |
| Part NumberiManufacturer catalog number | 711383 |
| BrandiManufacturer or product brand | Sealmaster |
| UPCiUniversal Product Code | 662461339220 |
| CategoryiCatalog classification | Bearings > Ball Bearings |
