Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 713806 |
| Product Name | TB-32RT |
| Brand | Sealmaster |
| Weight | 7.6 lb |
| Package Length | 6.06 in |
| Package Width | 5.94 in |
| Package Height | 2.19 in |
| Thread Size | 5/8-11 |
| Overall Length (in) | 5.44 in |
| Overall Height (in) | 4.63 in |
| Base Width (in) | 2 in |
| Overall Width (in) | 2.17 in |
| Bore Diameter (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $592.14 | — |
| 2 in |
| Thread Depth (in) | 0.88 in |
| Base to Center Height (in) | 2.252 in |
| Length Through Bore (in) | 2.0937 in |
| Centerline to Outermost Bearing Face (in) | 1.344 in |
| Bolt Spacing (in) | 4.000 in |
| Housing Base | Solid |
| Rolling Element | Ball Bearing |
| Bore Shape | Straight |
| Housing Construction | One Piece |
| Housing Color | Black |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Cage Material | PPS - Polyphenylene Sulfide |
| Housing Type | Pillow Block, Tapped Base |
| Seal Type | Felt Labyrinth Seal |
| Housing Style | Pillow Block |
| Locking Collar Outside Diameter (in) | 3.375 in |
| Inner Race Heat Treat Method | Zone-Hardened |
| Ability to Relubricate | Yes |
| Bearing Insert Finish | Black Oxide |
| Radial Clearance | Standard |
| End Cap Available | No |
| Inner Ring Outside Diameter (in) | 2.4688 in |
| Maximum Speed (RPM) | 5000 rpm |
| Insert | 1-2T |
| Static Load Rating (lb) | 5,216 lb |
| Housing Material | Cast Iron |
| Shaft Locking Type | Concentric |
| Dynamic Load Rating (lb) | 7,889 lb |
| Bearing Insert Material | 52100 Bearing Steel |
| Base Length (in) | 5.438 in |
| Size Code | 2-115 |
| Misalignment Capability | ±2.0° Misalignment - Static Only |
| Max Operating Temperature (F) | 220 °F |
| Cage Type | Land Riding Retainer |
| Housing Coating | Powder Coated |
| Lubricant | Lithium Complex NLGI 2 Grease |
| Bearing Type | Standard Duty |
| Grease Fitting Thread Size | 1/8 NPT |
| Fixed vs. Expansion | Fixed |
| Housing Width (in) | 2 in |
| HTC | 8483.20.8040 |
| Country of Origin | United States of America |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-118311 |
| Part NumberiManufacturer catalog number | 713806 |
| BrandiManufacturer or product brand | Sealmaster |
| UPCiUniversal Product Code | 662461070178 |
| CategoryiCatalog classification | Bearings > Ball Bearings |
