Browning Mounted Stainless Steel Four Bolt Flange Ball Bearing - 400 Series Stainless Steel - SS Setscrew Lock - Corrosion Resistant - SF4S-S219
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 764093 |
| Product Name | SF4S-S219 |
| Brand | Browning |
| Weight | 2.62 lb |
| Package Length | 4.5 in |
| Package Width | 1.69 in |
| Package Height | 4.56 in |
| Housing Material | Stainless Steel |
| Bore Shape | Straight |
| Expansion | No |
| Measure Units | Inch |
| Insert Material | 400 Series Stainless Steel |
| Retainer Type |
Datasheets, CAD drawings, and installation instructions are available on request.
Request Documentation| Ball Riding Retainer |
| Duty Series | Standard Duty |
| Insert No. | VS-S219 |
| Maximum Operating Temperature | 200 °F |
| Seal Type | Single Lip Contact Seal with Flinger |
| Rolling Element | Ball Bearing |
| Housing Base | Semi-Solid |
| Housing Type | Flange, Four Bolt |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-120115 |
| Part NumberiManufacturer catalog number | 764093 |
| BrandiManufacturer or product brand | Browning |
| CategoryiCatalog classification | Bearings > Flange Units |
