FHP BELTS
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 1094903 |
| Product Name | 4L820 |
| Brand | Browning |
| Material | Rubber |
| Weight | 0.49 lb |
| Package Length | 5.45 in |
| Package Width | 12 in |
| Package Height | 1.75 in |
| Pitch Length | 81 |
| Belt Section | 4L |
| Reinforcing cord material | Polyester |
| Color | Black |
| Standards met |
| Quantity | Price Each | Save |
|---|---|---|
| 1+ | $78.81 | — |
| ARPM IP-23 |
| Section Size | 4L |
| Construction Type | Wrapped |
| Belt Series | FHP Belts |
| Outside Length/Diameter (in) | 82 in |
| Overall Width (in) | 0.5 in |
| Operating Temperature [Max] ºF | 140 °F |
| Product Type | FHP Belt |
| Cross Section | 0.5 |
| Operating Temperature [Max] ºC | 60 °C |
| Width (in) | 0.5 in |
| Resistance Features | Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3 |
| Operating Temperature Range | -32 to +140 °F |
| Part Height | .312 |
| HTC | 4010.34.3000 |
| Country of Origin | Mexico |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-104733 |
| Part NumberiManufacturer catalog number | 1094903 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662289186143 |
| CategoryiCatalog classification | Belts |
