TORQ/PRO
Need help confirming fit? Send us the current part number, shaft size, housing photo, or equipment model.
| Part Number | 187836 |
| Product Name | TP70XMPB |
| Brand | Browning |
| Weight | 37 lb |
| Package Length | 10.1 in |
| Package Width | 9.7 in |
| Package Height | 10.6 in |
| Type | Torque Overload Devices |
| Total Length (in) | 4.33 in |
| Clutch size code | 70 |
| Sensor Plate | Yes |
| Number of Bolt Holes | 6 |
| Hub Diameter (in) |
| Quantity | Price Each | Save |
|---|---|---|
| 1 – 9 | $13595.41 | — |
| 10+ | $12951.12 | 5% off |
| 4.17 in |
| Torq/Pro Sprockets | STP70 |
| Sensor Travel | 0.13 |
| Bolt Hole Thread Size (in) | 3/8 | 16 in |
| Outside Diameter (in) | 8.63 in |
| Nominal Bore (in) | 1.26 in |
| Nut Diameter (in) | 6.18 in |
| Spring Diameter | 6.54 |
| Reset Type | Automatic |
| Speed Limit | 160 |
| Backlash | Small |
| Mounting Bolt Circle Diameter | 7.88 |
| Torque [Min] (N-m) | 293.8 |
| Unit Accuracy | 0.1 |
| Disconnect Method | Ball Detent |
| Outside Diameter (mm) | 219.202 mm |
| Series / Model | TP70 |
| Recovery Style | Jog |
| Bore Size (in) | 1.26 | 2.75 in |
| Detection Method | Ball Detent |
| Bore Shape | Straight Bore |
| Disc Spring Color | Yellow |
| Total Length (mm) | 109.982 mm |
| Product Type | Torq Pro Torque Limiter |
| Torque [Max] (N-m) | 1,079.15 |
| Bore (Max) (in) | 2.75 in |
| Torque Capacity [Max] (lb-ft) | 795.833333333333 |
| Flange Diameter (in) | 6.69 in |
| Torque Capacity [Min] (lb-ft) | 216.666666666667 |
| Max RPM | 160 |
| Torque Capacity [Min] (in-lb) | 2,600 |
| Torque Capacity [Max] (in-lb) | 9,550 |
| Bore (Min) (in) | 1.26 in |
| HTC | 8483.60.8000 |
| Country of Origin | Japan |
Always verify dimensions, load ratings, material, and seal type before ordering.
| GDS #iGDS internal part number | GDS-107710 |
| Part NumberiManufacturer catalog number | 187836 |
| BrandiManufacturer or product brand | Browning |
| UPCiUniversal Product Code | 662288442851 |
| CategoryiCatalog classification | Power Transmission > Belt Drive Accessories |
